    500 mm Vernier Caliper, 0.02 mm

    Hot selling vernier caliper offers 0~500 mm measuring range, 0.02 mm reading and carbon steel materials, rodless, durable, easy to use and carry. A fastening screw can lock any position of the vernier scale. Mechanical vernier caliper is used to measure length, depth and diameter in science labs, medical purposes, steel industries, aerospace industries, etc.
    SKU: SISCO-VC-500
    $238.21
    i h
    🚚 Free shipping
    🔙 30-day returns
    📅 Delivery: 7-12 days
    Overview


    The provided 500 mm vernier caliper is a measuring tool for measuring length, inner and outer diameters, and depth accurately. Rodless, carbon steel materials, 0.02 mm reading, stable, durable, long life, easy to use and carry. A fastening screw can lock any position of the vernier caliper. Vernier scale is widely used in science labs, medical purposes, steel industries, aerospace industries, etc.

    Vernier caliper
    • <Locked Anywhere> sisco mechanical vernier caliper comes with a semi-circular non-slip push handle and metal fastening screws. Any position of the vernier caliper can be locked, and the reading is retained for easy operation.
    • <Large measuring range> Mechanical vernier calipers can measure length, depth, inner diameter and outer diameter within the range of 0~500mm.
    Digital vernier scale

    <Made of Carbon Steel> The mechanical vernier caliper is made of carbon steel, and the main caliper and ruler frame are heat treated as a whole.

    <Durable Measuring Surface> Matte chrome with laser-scored lines. Matte chrome plating on the engraved surface of the main ruler and ruler frame, laser engraved lines, exquisite and durable. The scale of the vernier caliper is clear and the measurement is accurate.

    Applications

    Vernier caliper is a measuring tool commonly used by fitters and equipment maintenance personnel. It can directly measure the outer diameter, inner diameter, thickness, width, depth and hole distance of parts. sisco mechanical vernier calipers are available with 0~100 mm, 0~200 mm, 0~300 mm...0~600 mm measuring ranges, which are widely used in science labs, medical purposes, steel industries, aerospace industries and education sector.

    Vernier caliper applications

    Specs
    • Model: SISCO-VC-SG500
    • Range: 0~500mm
    • Weight: 760g
    • Material: Carbon Steel
    • Reading: 0.02mm
    • Product Packaging: Plastic Box

    Dimension (Unit: mm)

    500mm vernier caliper dimensions

    Range (mm) 0~500 Reading (mm) 0.02
    a (mm) 25 t (mm) 6
    A (mm) 100 B (mm) 10
    FAQs

    Q1: What is a vernier caliper?
    A1: Vernier caliper is a measuring tool for measuring length, inner and outer diameters, and depth. The vernier caliper is composed of two parts, the main ruler and the sliding vernier attached to the main ruler. The depth rod is connected to the vernier to measure the depth of the groove and cylinder.

    Q2: What are vernier calipers used for?
    A2: As a commonly used measuring tool, sisco vernier calipers can be specifically applied in the following four aspects:

    • Measure the width
    • Measuring the outer diameter
    • Measuring the inner diameter
    • Measure the depth

    Q3: How does a vernier caliper work?
    A3: Mechanical vernier caliper is a commonly used instrument for measuring length in the industry. It consists of a ruler body and a vernier that can slide on the caliper body. Viewed from the back, the cursor is a whole. There is a spring piece between the vernier and the caliper body, and the spring force of the spring piece is used to make the vernier and the caliper body close. There is a fastening screw on the upper part of the vernier, which can fix the vernier at any position on the body of the caliper.

    Tips: How to read the vernier calipers?

    1. Before using the vernier caliper to measure, you should first know the measurement accuracy and measurement range of the vernier caliper.
    2. The "0" line of the vernier caliper is the benchmark for reading millimeters. When reading, it is necessary to see clearly the scale lines of the caliper body and the vernier.
    3. The reading method of the vernier caliper is divided into three steps: reading integers, reading decimals, and summing.
    Warranty

    Thank you for buying industrial test and measurement equipment on SISCO.com, all products sold by SISCO and the partner cover a 12 months warranty, effective from the date of receiving the products.


    What is covered?

    SISCO is responsible for providing free spare parts, and free technical support to assist the customer to repair the defective products until the problem is solved.


    What is not covered?

    • Product purchased from anyone other than a SISCO store or a SISCO authorized reseller.
    • Expendable parts.
    • Routine cleaning or normal cosmetic and mechanical wear.
    • Damage from misuse, abuse or neglect.
    • Damage from use of parts other than SISCO approved.
    • Damage from use outside the product’s usage or storage parameters.
    • Damage from use of parts not sold by SISCO.
    • Damage from modification or incorporation into other products.
    • Damage from repair or replacement of warranted parts by a service provider other than a SISCO authorized service provider.
    • Damage caused by the application environment not meeting the product usage requirements and the failure to perform preventive maintenance.
